Focal SM9

เป็นคนแรกที่รีวิวสินค้านี้
฿ 360,000
สินค้าหมด
SKU
FOC-SM9
เพิ่มไปยังรายการโปรด เพิ่มไปเปรียบเทียบ
3-WAY MONITOR
Focal SM9
Focal SM9 Focal SM9 Focal SM9 Focal SM9 Focal SM9 Focal SM9 Focal SM9

SM9
This monitoring speaker establishes itself as a reference thanks to the precision of the stereo image, its capacity to reproduce each of the micro details of the audio signal, as well as unconditional respect of the original dynamics.
One of the major SM9 innovations lies in the fact of offering 2 monitoring speakers in only one and unique cabinet. The SM9 is thus composed of 2 monitors: a 3 way monitor and a 2 way monitor.

ข้อมูลเพิ่มเติม
ข้อมูลเพิ่มเติม
ข้อมูลจำเพาะ

Technical Specifications

  • Switchable 3-way/2-way active studio monitor
  • Construction of 0.88" and 1.2" panels with internal braces
  • High-frequency transducer: TB872, 1" pure Beryllium inverted dome tweeter
  • Midrange transducer: 6W0452, 6.5" Focal "W" composite sandwich cone driver
  • Low-frequency transducer: 8W7571, 8" Focal "W" composite sandwich cone driver
  • Passive radiator: 11WPP52, 11" Focal "W" composite sandwich cone piston, extra wide inverted surround radiator
  • Treble amplification of 100W (Class AB)
  • Midrange amplification of 100W (Class AB)
  • Bass amplification of 400W (Class AB)
  • 3-way mode frequency response of 30Hz-40kHz (+/- 3dB; +/- 1dB from 40Hz-20kHz)
  • 2-way (Focus Mode) mode frequency response of 90Hz-20kHz (+/- 3dB)
  • 3-way mode maximum SPL of 116dB SPL (peak at 1m)
  • 2-way (Focus Mode) mode maximum SPL of 106dB SPL (peak at 1m)
  • Electronically balanced input impedance
  • Input impedance of 10k ohms
  • XLR input connector
  • Adjustable input sensitivity (+4dBu or -10dBV)
  • Power supplies: 230V (3.15A fuse) or 115V (6.3A) via IEC inlet connection
  • Full-range, 45Hz, 60Hz, and 90Hz (-6dB) highpass crossover
  • Low-frequency shelving configuration of 30Hz-250Hz in 0.5dB steps (up to +/- 3dB)
  • High-frequency shelving configuration of 4.5kHz-40kHz in 0.5dB steps (up to +/- 3dB)
  • Low-frequency EQ control of +/-3dB (in 0.5dB steps) at 50Hz (Q factor = 2)
  • Low mid-frequency EQ control of +/-3dB (in 0.5dB steps) at 160Hz (Q factor = 1)
  • Mid-frequency EQ control of +/-3dB (in 0.5dB steps) at 1kHz (Q factor = .6)
  • Direct mode bypasses hardware EQ
  • Black finish, with natural veneering on top and bottom panels
  • 12.8" x 19.6" x 15.6" dimensions
  • 77 lbs. (35 kg.)
